ACS is a French certification established in 1999 which certifies the health compliance of products. ACS is a specific certification for products that come into contact with water for human consumption.

Official DAB pumps delegate who manages the sales of our products. Here you can find the list.

It is an acronym for American Iron and Steel Institute (AISI), an association of the North American steel producers. Nowadays used throughout the world, AISI is followed by a four-digit that identifies the properties of the steel alloy in use in that product.

The alternate current (AC) is a form of distribution of electrical power. In the AC the electric current periodically reverses direction. In Europe the AC power is at 400 volt at 50 Hz.

The word indicates a hermetic sealing system created by the pressure difference. In the common language "autoclave" mean a pump or a set of pumps to increase the pressure of the water for civil and industrial use (the E.sybox in this sense is an autoclave).

Depending on the direction of liquid passing through a pump, the pump can be called axial (or inline) if the delivery and suction are on the same axis.

Pressure measurement unit. The official measure for the International System is the Pascal “Pa” (the unit is named after Blaise Pascal, mathematician, physicist and French philosopher). Commonly are used the bar (all written down):

It is a perforated bucket-shaped container that in the pumps allows to filter solid bodies.

The bearing is a mechanical organ installed to balance the axial thrust of the vertical motor shafts. In 1910 the American engineer Albert Kingsbury invented an axial bearing, with a spherical pivot that allowed the oscillation according to the load applied in all directions, the Kingsbury bearing.

The bearing is a mechanical organ installed to balance the axial thrust of the vertical motor shafts. In 1905 the English engineer Anthony Michell invented an axial bearing, with a cylindrical pivot that allows the oscillation according to the load applied in all directions except in the radial one.

BIM is an English acronym that means "Building information modeling". In our case BIM means a file that can have different extensions, which can be used by designers to optimize the planning, implementation and management of building. Several software can handle BIM files, the most common being Autocad's Revit. The BIM file contains the parameters to render the object in 3D, including the overall dimensions, the electricity consumption and all the data necessary for its correct virtual representation.

It has the same function as the retention valve but is located inside the tank from which the pump draws the suction water.

It is synonymous with bearings. They consist of two different parts, where the first is housed in the body of the support and the other one is stuffed on the pivot of the body to be supported.

Electrical component that allows the operation of single-phase motors. It is necessary to ensure the starting of single-phase motors, It is not present in three-phase motors.

Usually cataphoretic means "painting by cataphoretic procedures", a painting treatment that gives alloys, steel or iron elements resistance to corrosion. During the process an epoxy or acrylic resin is deposited on the surface, followed by a final painting. The acrylic resin compared to the epoxy resin is more resistant to atmospheric agents.

Referring to pumps, cavitation is the phenomenon that occurs when the pressure in an inner point of the pump decreases by turning the liquid into gaseous state (bubbles, hence cavitations). The bubbles are unstable and when they come out of the low pressure zone they implode creating vibrations that in the long run will damage the material or the components of the pump. Usually the most exposed structure to this negative phenomenon is the impeller.

The centrifugal pump uses a impeller to move the liquid, aspirating and moving it by the centrifugal force determined by the mechanical movement of the impeller. All of our pumps are centrifugal.

It is a pump for moving the water in the heating system, a pump that runs water in a closed circuit, often with glycols.

A clear contact is a contact where there isn’t electrical tension.

Clear water are draining water: drain water and infiltration water, drain water from building basement; drained areas, rain water, water from roads, streets, parking areas. Drainage pumps can withstand particles to a size up to 10 mm.

A type of impeller not suitable for pumping liquids with suspended solid bodies, compared to open ones, they have a higher efficiency.

Type of electrical connection in the three-phase motors, the symbol for the delta connection is ∆. This type of connection bring to the wildings the same voltage of the line.

It is the power of a pump (the ability to lift water from one level to another). The capacity of a pump to elevate a certain number of cubic meters of water to a certain height, the maximum lift height, usually expressed in m3 (water column meters).

10 mca = 1 bar

Prevalence is given by several variables, such as the geodetic aspiration height and the geodetic height of the mandate.

Electronic component used in electronic devices. It is a group of switches who are manually switchable without the use of tools.

A tank that is installed between the water inlet pipe and the domestic plant and it is used to have more liquid available to keep the plant under pressure. It also provides a water reserve to meet requests when the user's demand is higher than that available from the aqueduct.

DNA (Dab Navigator Application) is DAB software that allows to find in just a few seconds the pump model that best suit your needs.
DNA uses two different logical selection criteria, for hydraulic performance or for pump model. DNA makes available to the user the entire spare parts list as well as all the technical documentation available. Frequent updating and easy to use. DNA is the perfect support tool for engineers, installers and retailers, even for the end users.

Direct On Line. A tri-phase motor can be started with a DOL connection or star-delta connection.

Draining water are: drain water and infiltration water, drain water from building basement; drained areas, rain water, water from roads, streets, parking areas. Drainage pumps can withstand particles to a size up to 10 mm.

"Dry run” is when the pump works without having liquid inside. A pump should never "dry run" because if it is not adequately cooled by the liquid some parts of the pump will overheat and breaks. The pumps have a device that prevents them from running in the absence of liquid.

Effluent water are industrial wastewater without toilet waste, water discharge from economic activity (water which has been used for production, including cooling and flushing water). Dirty water and untreated wastewater without discharge from toilets. Effluent water may contain fibers and suspended matters not bigger than 39 mm.

Motor connection point with electric line. In three-phase motors, the connection can be delta or star. You can change them by changing the position of the connector.

It is an English acronym meaning Energy Related Products. Despite the literal translation, in the common language means that the products comply with the European Union (ErP) 2009/125 EC law, which provides a reduction in energy consumption.

A family of computer networking technologies. Nowadays the Ethernet cable should at least be category 5e. The Ethernet cable has a connector called RJ-45.

Container that avoids the blows and ramps in the delivery on a hydraulic system. It also allows to deliver pressurized water in case of small demands.

Type of graphic representation of an object. In our DNA software an exploded product drawing is always present and serves to identify the exact code of the spare parts.

FDA is an acronym that indicates the Food and Drug Administration, the US entity that deals with regulating pharmaceuticals and food products on the market in the United States of America. It depends directly on the department of health and human services.

Circular plate for coupling tubes with screws or bolts.

Full solid handling means that the space between the impeller and the shim is as wide as the entry space of solid bodies. For example, if the solid handling is 40 mm, a pump with full solid handling will have a distance between the impeller and the shim of at least 40 mm.

Glycol is a chemical compound used as antifreeze in closed hydraulic circuit.

Hydraulic power is the hydraulic capacity of a pump, that is, the volume of liquid that is shifted to the unit of time. It is measured in cubic meters per hour (m3 / h) for very large pumps or liters per minute (l / m) for small and medium sized ones. There is a formula for converting values:

"Inrush" means that when starting a pump it will turn the impeller for a few moments faster then usual. It is a normal function, this function reduce the probability that any solid particles deposited during the stop will prevent proper movement.

A plumber or electrician who performs the installation of the product; He should be the reference person between the end user and the DAB Pumps customer service. He is the first person to contact in the event of a problems with our product.

It is called "installer menu" because changing the parameters in this menu affects the operation of the pump and must be performed by experienced personnel (as the installer). The procedures to enter in the installer menu is different for every products. All of our manuals are available on our site or here in our DNA software.

The intake duct is the pipe in which the liquid arrives to the pump.

It is the world's most widely-used unit of measurement (essentially used anywhere except in the U.S.), also known as a decimal metric system. It was founded in 1889 from the need to standardize the units of measure (among the proponent countries there was also the then Kingdom of Italy). It is called International System since 1961.

It is an acronym that stands for Internet of Things. It is a set of technologies that allows an object to transmit and receive information through the Internet. Smart thermostats are an example of the IoT. With the help of our D.Connect box a pump can became an IoT product.

Acronym of "International Protection" i.e. the degree of "international protection" (standard protection). It is indicated by two digits after the IP letters, the first one vary from a scale from 0 to 6 and indicates the protection at the entry of small solid bodies (sand or dust), 0 no protection, 6 maximum protection. The second number vary from a scale from 0 to 9 and indicates the protection from liquid entry, where 0 indicates the absence of protection, 9 the maximum protection.

meters of water column is the unit of measure of the prevalence, 10 mwc corresponds to 1 bar of pressure (100 KPa)

Motor lower part/end part (where for example our MCE-C variable frequency drive is installed).

The poles of an electric motor are the magnetic poles of the winding. The 4-pole motor runs slower than a 2-pole one.

The direction of rotation of an engine is invertible only in the case of three-phase motors (the single-phase motor always rotates in the right direction independently of the terminals connection). It is one of the features that must be checked when installing a three-phase pump, the rotation direction must always be the correct one to ensure the right operation. Each manual of our products tell you how to verify the correct direction of rotation, when the pump is already installed and before installation. If the direction of rotation is incorrect, remove the current and reverse two of the three phase conductors. Refer to the specific product manual here on our site or in our DNA software.

It means that the pump has two or more impellers (more impellers provide more prevalence and pressure).

NFC is an English acronym that stands for "Near Field Communication" a technology that allows the exchange of bidirectional data at a very short distance (a few centimeters). It is the technology normally used in shops with credit cards, smartwatches and smartphones to make contactless payments. Compared to bluetooth, data transmission takes place at a shorter distance and at very low speeds, making it suitable only for exchanging few amount of data.

Closure device that can be automatic or manual, allows only one direction of the flow; in the pumps is used to prevent the flow of the liquid to exit the pipes after the pump is switched off. A ball valve is commonly used in pipes (for gas or liquids), it works by rotating a ball inside the pipe that allows the opening, the closing or the reduction of the flow. Gate valve, unlike balls valve, use a shutter as a closing / opening pipe.

We need to know it to know where and when the cavitation can occur: NPSH (NPSHa)  is a measure of how close the fluid at a given point is to flashing, and so to cavitation. The Required NPSH (NPSHr): the head value at a specific point (e.g. the inlet of a pump) required to keep the fluid from cavitating.

NPSH stands for Net Positive Suction Head.
The physical meaning of this expression is the absolute pressure that must exist at the suction port of the pump in order to pump the liquid without
causing cavitation.
This can occur when the absolute pressure falls to values likely to allow the formation of vapour bubbles within the fluid, causing the pump to work with
reduced head.
Therefore, NPSH can also be seen as the pressure required to compensate load losses in the path between the suction port and the point with the lowest
pressure of the impeller.
All this demonstrates the importance of checking that the pump is not producing cavitation, as in addition to creating high noise similar to metal
hammering, cavitation will also quickly damage the impeller.
A special formula associates the NPSH value required by the pump with the conditions of the system and with the type of liquid, allowing to calculate the
minimum pressure required at the suction, and consequently to determine the position in which to locate the pump in relation to the free surface of the
liquid to be pumped.
The general NPSH formula is:



where:
Z1 = the difference in level (in m) between the axis of the pump and the free surface of the liquid to be pumped.
p1 = the possible pressure (in kg/cm2) on the surface of the liquid in the tank from which it is collected. If the liquid is collected from an open tank and
the surface of the liquid is in contact with the atmosphere, p1 will be equal to 0.
pb = atmospheric pressure (in kg/cm2) at the site of installation.
pv = the vapour tension (in kg/cm2) of the liquid at pumping temperature.
γ = the specific weight (in kg/dm2) of the liquid at pumping temperature.
10 = conversion factor of the units of measure used.
Hr = head loss (in m) in the suction pipework.

It is the outlet connection of a pump / circulator that connects to the pipe into which the liquid is conveyed.

It refers to the position of a pump. Overhead means that the pump is at a higher level than the liquid to be aspirated. Underhead means that the pump is at a lower level than the liquid to be aspirated.

Type of coating for electric cables, mainly used for submersible motors and pumps. PE2 stands for polyethylene 2, PA for polyamide. This type of coating allows higher voltage and support a higher temperature than PVC cables.

In chemistry, pH is a numeric scale used to specify the acidity or basicity of an aqueous solution. The scale is from 1 to 14. One is extremely acid, 14 extremely basic. 7 in neutral.

PLC is an acronym that stands for "Powerline Communication" a data transmission technology through the electricity network, rectified by the IEEE, Institute of Electrical and Electronics Engineers in 2011. It is the technology used from electricity meters to communicate consumption data. The PLC technology lets two devices communicate between them, just connect them to the power socket. The transmission is optimal only on single-phase systems and between devices connected under the same meter, without differential or magnetothermal switches between them.

Pressure means weight per unit of area (e.g. Kg/cm2). In case of liquids the pressure that the liquid exerts on a surface is given buy the product of the head of the liquid, multiplied by its specific weight. A Column of water of 10 m high is equivalent to approximately 1 Kg/cm2.

The pressure drops are the loss of energy caused by the rubbing of the liquid along the pipe walls (viscous friction) and the localized pressure drop due to the presence of shrinkage, curves, valves etc.

A device that allows to activate / deactivate a machine / engine when a given pressure value is reached.

Priming of a pump is defined as the phase during which the machine is filled with water through the intake duct. If the operation is successful, the machine can work smoothly and define as “primed". The priming must always be done manually following the procedure described in the manual. The manuals of all of our products can be found here on our website or in our DNA software.
